SADAS DS-T15 is a ballistic-protected optical periscope system engineered for safe external observation and high optical clarity in tanks and armored fighting vehicles. Featuring STANAG 4569 Level 4 ballistic protection, a 1064 nm laser protection filter, and an anti-reflective (AR) coating, it supports crew safety and situational awareness. Its dust- and sand-resistant design, optional metal or fabric protective covers, and resistance to vibration and mechanical shock ensure reliable performance under demanding operational conditions.
Environmental conditions
Waterproof
1m derinlik - 30 dakika
Storage temperature
-54 °C / +71 °C
Standard
MIL-STD-810H
Operating temperature
-54 °C / +71 °C
Technicial Specifications
| Dimensions |
330x108x265.2 mm
|
| Viewing Angle |
H: 79° / V: 21°
|
| Coverage Angle |
H: 93° / V: 25°
|
| Laser Protection |
1064 nm OD 5
|
| Ballistic Protection |
Level 4 - STANAG
|
| Weight |
14.3 kg
|
